Front Wheel Hub & Bearing Assembly for Ford F-150 2010-2014, 4WD / AWD, 7-Lug with ABS
Available in stock (20)
Front Wheel Hub & Bearing Assembly for Ford F-150 (2010-2014)
A complete front hub and bearing unit for the four-wheel-drive F-150. A failing bearing starts as a hum or growl that rises with road speed and changes as you sway the truck left and right, and left long enough it develops play at the wheel and can set ABS sensor faults. Because the bearing is already pressed into the hub as one sealed assembly, replacement is a bolt-off, bolt-on job with no press work, and each unit is quality tested to meet or exceed OEM performance standards.
Fitment
- Ford F-150 2010, 2011, 2012, 2013, 2014
- Drivetrain: 4WD or AWD only
- Wheel studs: 7-lug
- Brake system: ABS equipped
- Position: Front axle
- Quantity: 1 piece
- Not for: 2WD F-150, 6-lug trucks, rear applications, or 2015 and newer F-150
Two details decide this one: the truck must be 4WD or AWD, and it must be the 7-lug hub. Count the studs on your wheel and confirm your drivetrain by VIN, or match the dimensions and part numbers below, before ordering.
Replaces part numbers
- 513326
- BL3Z-1104-D
- BR930465, BR930801
- SP550221
Specifications
- Flange diameter: 7.48 in
- Flange offset: 1.79 in
- Bolt circle diameter: 5.91 in
- Studs: 7 lug
- ABS: Yes, for ABS-equipped vehicles
- Quality: Tested to meet or exceed OEM performance standards
Installation notes
- Installation should be carried out by a qualified technician.
- No press work is needed, as the bearing is already assembled into the hub.
- Torque the hub and axle fasteners to the vehicle's factory specifications.
- Check that the ABS warning light clears, then test the truck in a safe area.
FAQ
Does it fit a 2WD F-150? No. This hub covers 4WD and AWD trucks only.
How do I know if I have the 7-lug hub? Count the wheel studs. This assembly is for the 7-stud pattern with a 5.91 in bolt circle.
Is the bearing included? Yes, pressed into the hub as one sealed assembly.
Does it fit a 2015 F-150? No. The 2015 model year began a new generation with different front hubs.
