Front Wheel Hub Bearing Assembly for 2005-2010 Chevy, 2003-2007 Saturn, 2005-2010 Pontiac
Available in stock (20)
Front Wheel Hub Bearing Assembly — 513205 (4-Lug, Non-ABS, Front) — 2005–2010 Chevy Cobalt / 2003–2007 Saturn Ion / 2007–2010 Pontiac G5 / 2005–2006 Pontiac Pursuit — GM Delta Platform
This hub assembly does NOT include an ABS sensor ring. It is designed for GM Delta platform variants not equipped with an ABS-integrated hub sensor. Some Cobalt, Ion, G5, and Pursuit configurations were built without ABS or with an ABS sensor located separately from the hub. Installing this Non-ABS hub on a vehicle that requires an ABS-integrated hub will result in ABS system malfunction and warning lights. Confirm your vehicle's hub ABS sensor configuration before ordering. Contact us with your VIN if unsure.
Full Vehicle Compatibility — GM Delta Platform (Front Hub, Non-ABS, 4-Lug)
| Make | Model | Years | Notes |
|---|---|---|---|
| Chevrolet | Cobalt | 2005–2010 | Delta platform — Non-ABS hub configuration |
| Saturn | Ion | 2003–2007 | Delta platform — Non-ABS hub configuration (Saturn discontinued 2010) |
| Pontiac | G5 | 2007–2010 | Delta platform — Cobalt-based, sold in US (Pontiac discontinued 2010) |
| Pontiac | Pursuit | 2005–2006 | Delta platform — Cobalt-based, Canadian market variant |
The Pontiac G5 and Pursuit are Pontiac-badged variants of the Chevrolet Cobalt on the same GM Delta platform. The Pontiac Pursuit (2005–2006) was sold primarily in Canada and select export markets. The Saturn Ion shares the same Delta platform front hub geometry on Non-ABS variants. All listings: Non-ABS, 4-lug configuration. Confirm your hub ABS sensor configuration via VIN before ordering. Contact us for fitment verification.
Part Specifications
| Specification | Details |
|---|---|
| Part Number | 513205 |
| SKU | SA-513205 (single unit) |
| Position | Front (single unit — left or right) |
| Lug Count | 4 Lugs (4×100 — NOT 5-lug) |
| ABS | Non-ABS — No integrated ABS sensor ring |
| Weight | ~3.12 kg (single unit) |
Key Features
- GM Delta Platform Front Hub — Non-ABS, 4-Lug: Correct front hub specification for Non-ABS, 4-lug variants of the Chevy Cobalt (2005–2010), Saturn Ion (2003–2007), Pontiac G5 (2007–2010), and Pontiac Pursuit (2005–2006). Confirm ABS configuration and lug count before ordering.
- Discontinued Brand Support: Full availability for Saturn (discontinued 2010) and Pontiac (discontinued 2010) vehicles. The GM Delta platform front hub specification is shared across all four models.
- Non-ABS Construction: No integrated ABS tone ring. For Delta platform configurations where the ABS sensor is not hub-integrated or where ABS is not installed. Confirm hub ABS configuration via VIN before ordering.
- OEM-Equivalent Quality: Meets or exceeds OEM performance standards. Tested for load rating and bearing clearance before shipment.
- Complete Assembly: Hub and bearing pre-assembled — no press-fit or bearing packing required.
Installation Notes
- Professional installation recommended for GM Delta platform front hub replacement.
- Confirm Non-ABS hub configuration before installation. Installing a Non-ABS hub where an ABS-integrated hub is required will cause ABS system faults and warning lights.
- Torque all fasteners to OEM specification.
- For both front corners, order quantity 2.
Note: Single unit, front position. Non-ABS, 4-lug. 513205. Fits 2005–2010 Chevy Cobalt, 2003–2007 Saturn Ion, 2007–2010 Pontiac G5, 2005–2006 Pontiac Pursuit — Non-ABS hub configuration and 4-lug only. Verify ABS config and lug count via VIN before ordering.
