Rear Wheel Hub & Bearing Assembly for Toyota Sienna 2004-2010, FWD, 5-Lug with ABS
Available in stock (20)
Rear Wheel Hub & Bearing Assembly for Toyota Sienna (2004-2010)
A complete rear hub and bearing unit for the front-wheel-drive Sienna. A failing wheel bearing announces itself as a hum or growl that rises with road speed and changes when you sway the van left and right, and on ABS-equipped vehicles it can also trigger wheel speed sensor faults. Because the bearing comes pressed into the hub as one sealed assembly, the repair is a bolt-off, bolt-on job rather than a press-and-pack exercise. Every unit is quality tested to meet or exceed OEM performance standards.
Fitment
- Toyota Sienna 2004-2010
- Drivetrain: Front-wheel drive only
- Wheel studs: 5-lug
- Brake system: ABS equipped
- Position: Rear axle
- Not for: AWD Sienna, non-ABS vehicles, front applications, or 2011 and newer Sienna
Drivetrain and ABS both matter here: the AWD Sienna uses a different rear hub. Confirm your configuration by VIN, or match the dimensions and part numbers below, before ordering.
Replaces part numbers
- 512280
- BR930437
Specifications
- Flange diameter: 5.98 in
- Flange offset: 2.72 in
- Bolt circle diameter: 4.5 in
- Studs: 5 lug
- ABS: Yes, for ABS-equipped vehicles
- Quality: Tested to meet or exceed OEM performance standards
Installation notes
- Installation should be carried out by a qualified technician.
- No press work is needed, as the bearing is already assembled into the hub.
- Torque the hub and axle fasteners to the vehicle's factory specifications.
- Check that the ABS warning light clears and test the vehicle in a safe area before normal driving.
FAQ
Does it fit an AWD Sienna? No. This hub covers front-wheel-drive models only.
Is the bearing included? Yes. The bearing is pressed into the hub as a single sealed assembly.
Will it work on a non-ABS van? No. This unit is for ABS-equipped vehicles.
How do I confirm fitment? Cross-reference 512280 or BR930437, and check the 4.5 in bolt circle and 5-lug pattern against your existing hub.
