Timing Belt Kit with Water Pump for 2004-2008 Chevy Aveo & 2006-2008 Aveo5

Timing Belt Kit with Water Pump for Chevrolet Aveo and Aveo5

Engine timing-belt service kit with water pump, tensioner, idler, and seals for the specific Chevrolet Aveo and Aveo5 years listed below.

Critical fitment warning: The available source does not specify engine displacement, engine code, transmission, production-date breakpoints, or market-specific engine variations. Do not order by model and year alone. Confirm the VIN, engine label, original belt tooth count, belt width and profile, tensioner and idler design, water-pump mounting pattern, and reference number before ordering.

Vehicle Compatibility

• 2004–2008 Chevrolet Aveo
• 2006–2008 Chevrolet Aveo5

Aveo5 fitment begins in 2006 in the available source. Confirm the exact engine code and original timing components.

Package Contents

• One water pump with seal
• One timing belt — 127 teeth
• One tensioner bearing assembly
• One left-lower idler
• Two camshaft seals
• One oil-pump seal

Thermostat, coolant, timing-cover gaskets, crankshaft seal, accessory belts, pulleys, mounting bolts, and other service parts are not confirmed in the available source.

Reference Number

TCK335.

The reference number is provided for comparison. Confirm it together with the engine code, 127-tooth belt, belt dimensions, tensioner, idler, pump design, and seal sizes.

Installation Notes

Timing-belt and water-pump service is an advanced engine repair and professional installation is strongly recommended. Incorrect camshaft or crankshaft timing can cause severe engine damage. Drain and handle coolant according to local requirements, and do not reuse contaminated coolant. Clean the water-pump mounting surface thoroughly without damaging it, and follow Chevrolet’s procedures for engine timing, belt routing, tension setting, seal installation, water-pump mounting, fastener torque, coolant filling, and air bleeding. Rotate the engine by hand through the specified cycles and recheck timing marks and belt tension before starting. After start-up, inspect for coolant or oil leaks and verify normal operating temperature.

Frequently Asked Questions

Does this fit every engine offered in these model years?
The source does not state engine displacement or code. Verify the VIN, engine label, original belt, and pump before ordering.

Is the water-pump seal included?
Yes. The available package list specifies one water pump with seal.

How many teeth does the timing belt have?
The included timing belt is specified with 127 teeth.
